| PartNumber | LD420WUB-SCG1 |
| Značka | LG Display |
| Velikost | 42 |
| aplikace | PID |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 500 |
| CR | 1200:1 |
| Barvy | 16.7M/1.06B |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | LG Display |
| panelový model | LD420WUB-SCG1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 42 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | S-IPS, Normally Black, Transmissive |
| aktivní oblast | 930.24×523.26 mm |
| obrys | 956.4×549.4×54.5 mm, Videowall Seam 26.2 mm |
| povrch | Antiglare (Haze 10%), Hard coating (3H) |
| jas | 500 cd/m² (Typ.) |
| kontrastní poměr | 1200:1 (Typ.) |
| zobrazit barvy | 16.7M/1.06B (8-bit / 8-bit + FRC) |
| Doba odezvy | 10 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | CCFLEmbedded (Inverter) |
| signálové rozhraní | LVDS (2 ch, 8/10-bit), 51 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | PID |
| LC420DUN-SFU3 | LG Display | 42 | 1920×1080 |
| LC420EUF-SDA1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SBA1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SBG1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SCA1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SCB1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SCC1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SCG1 | LG Display | 42 | 1920×1080 |
| LD420WUN-SCA1 | LG Display | 42 | 1920×1080 |
| LD420WXN-SAA1 | LG Display | 42 | 1366×768 |
| LD470DUP-SEH2 | LG Display | 47 | 1920×1080 |
| LD550EUD-UFA1 | LG Display | 55 | 1920×1080 |
| LD650EUF-FHB1 | LG Display | 65 | 1920×1080 |
| LTI320AP01 | Samsung | 31.5 | 1366×768 |
| LTI400HA03 | Samsung | 40 | 1920×1080 |
| LTI820HD03 | Samsung | 82 | 1920×1080 |
| P546HW03 V0 | AUO | 55 | 1920×1080 |
| P550HVN06.0 | AUO | 55 | 1920×1080 |
| P650HVN02.6 | AUO | 65 | 1920×1080 |
| S290AJ1-LE1 | Innolux | 29.0 | 1920×540 |
