| PartNumber | LD420WUN-SCA1 |
| Značka | LG Display |
| Velikost | 42 |
| aplikace | PID |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 500 |
| CR | 1300:1 |
| Barvy | 16.7M/1.06B |
| Podsvícení | EEFL |
| Rozhraní | LVDS |
| značka panelu | LG Display |
| panelový model | LD420WUN-SCA1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 42 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | S-IPS, Normally Black, Transmissive |
| aktivní oblast | 930.24×523.26 mm |
| obrys | 983×576 mm |
| povrch | Antiglare (Haze 10%), Hard coating (3H) |
| jas | 500 cd/m² (Typ.) |
| kontrastní poměr | 1300:1 (Typ.) |
| zobrazit barvy | 16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172% |
| Doba odezvy | 10 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | EEFLEmbedded (Inverter) |
| signálové rozhraní | LVDS (2 ch, 8/10-bit), 51 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | PID |
