| PartNumber | LD470DXS-SCA1 |
| Značka | LG Display |
| Velikost | 47 |
| aplikace | DID |
| Rozlišení | 1366×768 |
| Složení | LCM |
| Jas | 800 |
| CR | 1400:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | LG Display |
| panelový model | LD470DXS-SCA1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 47 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| zobrazovací mód | S-IPS, Normally Black, Transmissive |
| aktivní oblast | 1039.87×584.64 mm |
| obrys | 1046.8×591.6×50.5 mm, Videowall Seam 6.9 mm |
| povrch | Hard coating (3H), Reflection 2.0% (Max.) |
| jas | 800 cd/m² (Typ.) |
| kontrastní poměr | 1400:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 12 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 8-bit), 30 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | DID |
