| PartNumber | LM220WE1-TLP1 |
| Značka | LG Display |
| Velikost | 22.0 |
| aplikace | DMPC |
| Rozlišení | 1680×1050 |
| Složení | LCM |
| Jas | 250 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | LG Display |
| panelový model | LM220WE1-TLP1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 22.0 inch |
| rozlišení | 1680(RGB)×1050 , WSXGA+ |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 473.76×296.1 mm |
| obrys | 493.7×320.1 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Doba odezvy | 1.3/3.7 (Typ.)(Tr/Td) |
| úhel pohledu | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| LM220W1-A2MN | LG Display | 22.0 | 1600×1024 |
| LM220WE1-TLB2 | LG Display | 22.0 | 1680×1050 |
| LM220WE1-TLB3 | LG Display | 22.0 | 1680×1050 |
| LM220WE1-TLD2 | LG Display | 22.0 | 1680×1050 |
| LM220WE1-TLE2 | LG Display | 22.0 | 1680×1050 |
| LM220WE1-TLK1 | LG Display | 22.0 | 1680×1050 |
| LM220WE1-TLM1 | LG Display | 22.0 | 1680×1050 |
| LM220WE1-TLP1 | LG Display | 22.0 | 1680×1050 |
| LM220WE3-TLA1 | LG Display | 22.0 | 1680×1050 |
| LM220WE5-TLA1 | LG Display | 22.0 | 1680×1050 |
| LM150X08-A4K3 | LG Display | 15.0 | 1024×768 |
| LM190E09-TLB1 | LG Display | 19.0 | 1280×1024 |
| LM215DT7A | PANDA | 21.5 | 1920×1080 |
| LM300WQ5-SDA1 | LG Display | 30.0 | 2560×1600 |
| LQ315D1JG93 | SHARP | 31.5 | 3840×2160 |
| LTM170ET01 | Samsung | 17.0 | 1280×1024 |
| LTM170W1-L01 | Samsung | 17.0 | 1280×768 |
| M220Z1-L01 | Innolux | 22.0 | 1680×1050 |
| M240HTN01.2 | AUO | 24.0 | 1920×1080 |
| TMS150XG1-10TB Rev.E | Tianma | 15.0 | 1024×768 |
