| PartNumber | LP156WF3-SLB1 |
| Značka | LG Display |
| Velikost | 15.6 |
| aplikace | NBPC |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 210 |
| CR | 800:1 |
| Barvy | 1.07B |
| Podsvícení | RGB LED |
| Rozhraní | LVDS |
| značka panelu | LG Display |
| panelový model | LP156WF3-SLB1 2 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.6 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | S-IPS, Normally Black, Transmissive |
| aktivní oblast | 344.16×193.59 mm |
| obrys | 359.3×212.1×7.2 mm |
| tvarový styl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| povrch | Antiglare, Hard coating (3H) |
| jas | 210 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 1.07B (10-bit), CIE1931110% |
| Doba odezvy | 30 (Typ.)(Tr+Td); 15 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | RGB LEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 10-bit), 50 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
