| PartNumber | LQ10DH15 |
| Značka | SHARP |
| Velikost | 10.4 |
| aplikace | IA |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 100 |
| CR | 60:1 |
| Barvy | 512 |
| Podsvícení | CCFL |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LQ10DH15 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.4 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 211.2×158.4 mm |
| obrys | 283×217 mm |
| povrch | Antiglare, Hard coating (2H) |
| jas | 100 cd/m² (Typ.) |
| kontrastní poměr | 60:1 (Min.) |
| zobrazit barvy | 512 (3-bit) |
| Doba odezvy | 30/50 (Typ.)(Tr/Td) |
| úhel pohledu | 45/45/10/30 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 6 pcsCCFLWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 3-bit), 22 pins |
| vstupní napětí | 5.0/12.0V (Typ.)(VCC/VDD) |
| aplikace | IA |
