| PartNumber | LQ190N1LW01 |
| Značka | SHARP |
| Velikost | 19.0 |
| aplikace | IA |
| Rozlišení | 1680×1050 |
| Složení | LCM |
| Jas | 300 |
| CR | 900:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | SHARP |
| panelový model | LQ190N1LW01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 19.0 inch |
| rozlišení | 1680(RGB)×1050 , WSXGA+ |
| zobrazovací mód | VA, Normally Black, Transmissive |
| aktivní oblast | 409.5×255.94 mm |
| obrys | 444×283.3×16 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 900:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193170% |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | IA |
