| PartNumber | TX31D200VM0BAA |
| Značka | KOE |
| Velikost | 12.3 |
| aplikace | IA |
| Rozlišení | 1280×480 |
| Složení | LCM |
| Jas | 1000 |
| CR | 1000:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | KOE |
| panelový model | TX31D200VM0BAA |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 12.3 inch |
| rozlišení | 1280(RGB)×480 , DVGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 291.84×109.44 mm |
| obrys | 320×130×12.6 mm |
| povrch | Antiglare |
| jas | 1000 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193170% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 6-bit), 20 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
