| PartNumber | LTL090CL01-002 |
| Značka | Samsung |
| Velikost | 9.0 |
| aplikace | PAD |
| Rozlišení | 1920×1280 |
| Složení | LCM |
| Jas | |
| CR | 800:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | SAMSUNG |
| panelový model | LTL090CL01-002 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 9.0 inch |
| rozlišení | 1920(RGB)×1280 |
| zobrazovací mód | PLS, Normally Black, Transmissive |
| aktivní oblast | 190.08×126.72 mm |
| obrys | 200.91×141.21×2.73 mm |
| povrch | |
| jas | |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193150% |
| Doba odezvy | 16 (Typ.)(Tr+Td) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLED |
| signálové rozhraní | MIPI (4 data lanes), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
