| PartNumber | LD070WX4-SM01 |
| Značka | LG Display |
| Velikost | 7.0 |
| aplikace | PAD |
| Rozlišení | 800×1280 |
| Složení | LCM |
| Jas | 490 |
| CR | 800:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | LG Display |
| panelový model | LD070WX4-SM01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 800(RGB)×1280 , WXGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 94.2×150.72 mm |
| obrys | 104.32×161.67×3.57 mm |
| povrch | Hard coating |
| jas | 490 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC) |
| Doba odezvy | 50 (Max.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 5S5PWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 34 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
