| PartNumber | LTL097QL01-W01 |
| Značka | Samsung |
| Velikost | 9.7 |
| aplikace | PAD |
| Rozlišení | 2048×1536 |
| Složení | LCM |
| Jas | 420 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | SAMSUNG |
| panelový model | LTL097QL01-W01 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 9.7 inch |
| rozlišení | 2048(RGB)×1536 , QXGA |
| zobrazovací mód | PLS, Normally Black, Transmissive |
| aktivní oblast | 196.608×147.456 mm |
| obrys | 208.88×167.12×5.02 mm |
| povrch | Glare (Haze 0%), Hard coating (2H), Reflection 1.45% (Max.) |
| jas | 420 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 16 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhraní | eDP (4 Lanes), 51 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
