| PartNumber | LTM201M1-L01 |
| Značka | Samsung |
| Velikost | 20.1 |
| aplikace | DMPC |
| Rozlišení | 1680×1050 |
| Složení | LCM |
| Jas | 300 |
| CR | 900:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | SAMSUNG |
| panelový model | LTM201M1-L01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 20.1 inch |
| rozlišení | 1680(RGB)×1050 , WSXGA+ |
| zobrazovací mód | S-PVA, Normally Black, Transmissive |
| aktivní oblast | 433.44×270.9 mm |
| obrys | 459.4×296.4 mm |
| povrch | Antiglare (Haze 44%), Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 900:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 16 (Typ.)(Tr+Td); 8 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | DMPC |
