| PartNumber | LM270WQ1-SLC1 |
| Značka | LG Display |
| Velikost | 27.0 |
| aplikace | DMPC |
| Rozlišení | 2560×1440 |
| Složení | LCM |
| Jas | |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | LG Display |
| panelový model | LM270WQ1-SLC1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 27.0 inch |
| rozlišení | 2560(RGB)×1440 , Quad-HD |
| zobrazovací mód | AH-IPS, Normally Black, Transmissive |
| aktivní oblast | 596.736×335.664 mm |
| obrys | 630×368.2×15.4 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), sRGB |
| Doba odezvy | 12 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhraní | LVDS (4 ch, 10-bit), 92 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | DMPC |
