| PartNumber | LTM240CT03 |
| Značka | Samsung |
| Velikost | 24.0 |
| aplikace | DMPC |
| Rozlišení | 1920×1200 |
| Složení | LCM |
| Jas | 400 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | SAMSUNG |
| panelový model | LTM240CT03 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 24.0 inch |
| rozlišení | 1920(RGB)×1200 , WUXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 518.4×324 mm |
| obrys | 546.4×352×36.3 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H), Antireflection |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193192% |
| Doba odezvy | 5 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| LM240WU8-SLA2 | LG Display | 24.0 | 1920×1200 |
| LM240WU8-SLD2 | LG Display | 24.0 | 1920×1200 |
| LTM240CL01 | Samsung | 24.0 | 1920×1200 |
| LTM240CL04 | Samsung | 24.0 | 1920×1200 |
| LTM240CS02 | Samsung | 24.0 | 1920×1200 |
| LTM240CS09 | Samsung | 24.0 | 1920×1200 |
| LTM240CT01 | Samsung | 24.0 | 1920×1200 |
| LTM240CT03 | Samsung | 24.0 | 1920×1200 |
| LTM240CT04 | Samsung | 24.0 | 1920×1200 |
| LTM240CT06 | Samsung | 24.0 | 1920×1200 |
| ITQX20H | IDTech | 20.8 | 2048×1536 |
| LM185TT4A | PANDA | 18.5 | 1366×768 |
| LM215WF3-SLA1 | LG Display | 21.5 | 1920×1080 |
| LM300W01-STA4 | LG Display | 30.0 | 2560×1600 |
| LTM220MT12 | Samsung | 22.0 | 1680×1050 |
| M200HJJ-L20 | Innolux | 19.5 | 1920×1080 |
| M200O3-LA3 | Innolux | 20.0 | 1600×900 |
| M236H3-LA3 | Innolux | 23.6 | 1920×1080 |
| MV215FHM-N30 | BOE | 21.5 | 1920×1080 |
| SVA190WX05TB | SVA-NEC | 19.0 | 1440×900 |
