| PartNumber | M190MWW3 R0 |
| Značka | IVO |
| Velikost | 19.0 |
| aplikace | DMPC |
| Rozlišení | 1440×900 |
| Složení | LCM |
| Jas | 300 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | IVO |
| panelový model | M190MWW3 R0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 19.0 inch |
| rozlišení | 1440(RGB)×900 , WXGA+ |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 408.24×255.15 mm |
| obrys | 428×278×17 mm |
| povrch | Antiglare, Hard coating |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Doba odezvy | 5 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| HSD190MEN3-A03 | HannStar | 19.0 | 1280×1024 |
| LM190E08-TLGD | LG Display | 19.0 | 1280×1024 |
| LM190WX1-TLL1 | LG Display | 19.0 | 1440×900 |
| LTM190EX-L21 | Samsung | 19.0 | 1280×1024 |
| M190EN04 V1 | AUO | 19.0 | 1280×1024 |
| M190MWW3 R0 | IVO | 19.0 | 1440×900 |
| M190MWW4 R2 | IVO | 19.0 | 1440×900 |
| MT190AW01 V.5 | Innolux | 19.0 | 1440×900 |
| NL128102BC29-01B | NLT | 19.0 | 1280×1024 |
| TX48D80VM1CAA | KOE | 19.0 | 1024×768 |
| HT236F01-100 | BOE | 23.6 | 1920×1080 |
| ITSX98E | IDTech | 18.1 | 1280×1024 |
| LM190E05-SL03 | LG Display | 19.0 | 1280×1024 |
| LM190WX1-TLA1 | LG Display | 19.0 | 1440×900 |
| LM270WQ1-SDB3 | LG Display | 27.0 | 2560×1440 |
| LTM190E1-L03 | Samsung | 19.0 | 1280×1024 |
| M170EG01 VD | AUO | 17.0 | 1280×1024 |
| M236HGJ-L11 | Innolux | 23.6 | 1920×1080 |
| MT216WW01 V.0 | Innolux | 21.6 | 1680×1050 |
| NA19020-C961 | Fujitsu | 19.0 | 1280×1024 |
