| PartNumber | TX48D80VM1CAA |
| Značka | KOE |
| Velikost | 19.0 |
| aplikace | GM |
| Rozlišení | 1024×768 |
| Složení | LCM |
| Jas | 400 |
| CR | 200:1 |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | HITACHI |
| panelový model | TX48D80VM1CAA |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 19.0 inch |
| rozlišení | 1024(RGB)×768 , XGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 385.536×289.152 mm |
| obrys | 410×324×17.5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 200:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 30/20 (Typ.)(Tr/Td) |
| úhel pohledu | 65/65/45/60 (Typ.)(CR≥5)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (1 ch, 6-bit), 20 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | GM |
