| PartNumber | M240UP01 V0 |
| Značka | AUO |
| Velikost | 24.0 |
| aplikace | DMPC |
| Rozlišení | 1920×1200 |
| Složení | LCM |
| Jas | 250 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | Analog + Digital |
| značka panelu | AUO |
| panelový model | M240UP01 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 24.0 inch |
| rozlišení | 1920(RGB)×1200 , WUXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 518.4×324 mm |
| obrys | 546.4×352 mm |
| povrch | Antiglare |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC) |
| Doba odezvy | 3.8/1.2 (Typ.)(Tr/Td); 2 (Typ.)(G to G) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhraní | Analog RGB + DVI-D, 70 pins |
| aplikace | DMPC |
| LM240WU7-SLA3 | LG Display | 24.0 | 1920×1200 |
| LM240WU8-SLD2 | LG Display | 24.0 | 1920×1200 |
| LM240WU8-SLD4 | LG Display | 24.0 | 1920×1200 |
| M240HTN01.2 | AUO | 24.0 | 1920×1080 |
| M240UP01 V0 | AUO | 24.0 | 1920×1200 |
| M240UW01 V0 | AUO | 24.0 | 1920×1200 |
| M240UW01 V2 | AUO | 24.0 | 1920×1200 |
| M240UW01 V3 | AUO | 24.0 | 1920×1200 |
| M240UW04 V0 | AUO | 24.0 | 1920×1200 |
| M240UW04 V1 | AUO | 24.0 | 1920×1200 |
| LM190E09-TLD1 | LG Display | 19.0 | 1280×1024 |
| LM201WE3-TLE1 | LG Display | 20.1 | 1680×1050 |
| LM230WF5-TLB1 | LG Display | 23.0 | 1920×1080 |
| LM238WF4-SSA1 | LG Display | 23.8 | 1920×1080 |
| LTM170E4-P01 | Samsung | 17.0 | 1280×1024 |
| M201UN04 V0 | AUO | 20.1 | 1600×1200 |
| M236HGJ-L11 | Innolux | 23.6 | 1920×1080 |
| M238DAN01.1 Q0 | AUO | 23.8 | 2560×1440 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| P270MWN1 R0 | IVO | 27.0 | 1920×1080 |
