| PartNumber | NL12876BC26-25 |
| Značka | NLT |
| Velikost | 15.3 |
| aplikace | IA |
| Rozlišení | 1280×768 |
| Složení | LCM |
| Jas | 470 |
| CR | 700:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | NEC |
| panelový model | NL12876BC26-25 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.3 inch |
| rozlišení | 1280(RGB)×768 , WXGA |
| zobrazovací mód | SA-SFT, Normally Black, Transmissive |
| aktivní oblast | 334.08×200.45 mm |
| obrys | 358×226 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 470 cd/m² (Typ.) |
| kontrastní poměr | 700:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193140% |
| Doba odezvy | 14/11 (Typ.)(Tr/Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (1 ch, 8-bit), 20 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
