| PartNumber | NL12876BC15-01 |
| Značka | NLT |
| Velikost | 8.9 |
| aplikace | NBPC |
| Rozlišení | 1280×768 |
| Složení | LCM |
| Jas | 280 |
| CR | 500:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | NEC |
| panelový model | NL12876BC15-01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 8.9 inch |
| rozlišení | 1280(RGB)×768 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 193.92×116.352 mm |
| obrys | 209.2×130.3×7.7 mm |
| povrch | Clear, Hard coating (3H) |
| jas | 280 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193156% |
| Doba odezvy | 6/2 (Typ.)(Tr/Td) |
| úhel pohledu | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 11S3PWLEDWithout Driver |
| signálové rozhraní | LVDS (1 ch, 6-bit), 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
