| PartNumber | NL6448AC30-10 |
| Značka | NLT |
| Velikost | 9.4 |
| aplikace | IA |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 90 |
| CR | 110:1 |
| Barvy | 4096 |
| Podsvícení | CCFL |
| Rozhraní | TTL |
| značka panelu | NEC |
| panelový model | NL6448AC30-10 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 9.4 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 192×144 mm |
| obrys | 259.5×179×12.5 mm |
| povrch | |
| jas | 90 cd/m² (Typ.) |
| kontrastní poměr | 110:1 (Typ.) |
| zobrazit barvy | 4096 (4-bit), CIE193155% |
| Doba odezvy | 40 (Max.)(Tr+Td) |
| úhel pohledu | 45/45/25/25 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1 pcsCCFLEmbedded (Inverter) |
| signálové rozhraní | CMOS (1 ch, 4-bit), 34 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | IA |
