| PartNumber | NL6448BC18-01 |
| Značka | NLT |
| Velikost | 5.7 |
| aplikace | IA |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 400 |
| CR | 850:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | NEC |
| panelový model | NL6448BC18-01 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.7 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 116.16×87.12 mm |
| obrys | 135×104.6×10.9 mm |
| povrch | Clear, Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 850:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193160% |
| Doba odezvy | 3/15 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 9S2PWLEDWithout Driver |
| signálové rozhraní | CMOS (1 ch, 6-bit), 33 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
