| PartNumber | PW080XU4 |
| Značka | E Ink |
| Velikost | 8.0 |
| aplikace | CNS |
| Rozlišení | 480×220 |
| Složení | LCM |
| Jas | 300 |
| CR | 400:1 |
| Barvy | Full color |
| Podsvícení | WLED |
| Rozhraní | Analog |
| značka panelu | PVI |
| panelový model | PW080XU4 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 8.0 inch |
| rozlišení | 480(RGB)×220 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 180.72×94.27 mm |
| obrys | 193×108.3×7 mm |
| povrch | Antiglare |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | Full color |
| Doba odezvy | 15/25 (Typ.)(Tr/Td) |
| úhel pohledu | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S9PWLEDWithout Driver |
| signálové rozhraní | TFT Specific Analog RGB, 30 pins |
| vstupní napětí | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VCCG/AVDD/VGH/VEE) |
| aplikace | CNS |
