| PartNumber | QD14FL02 Rev.01 |
| Značka | QDI |
| Velikost | 14.1 |
| aplikace | NBPC |
| Rozlišení | 1400×1050 |
| Složení | LCM |
| Jas | 175 |
| CR | 300:1 |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | QDI |
| panelový model | QD14FL02 Rev.01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 14.1 inch |
| rozlišení | 1400(RGB)×1050 , SXGA+ |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 285.7×214.3 mm |
| obrys | 299×240.6×5.5 mm |
| tvarový styl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| povrch | Antiglare, Hard coating (3H) |
| jas | 175 cd/m² (Typ.) |
| kontrastní poměr | 300:1 (Min.) |
| zobrazit barvy | 262K (6-bit), CIE193150% |
| Doba odezvy | 10/15 (Typ.)(Tr/Td) |
| úhel pohledu | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1 pcsCCFLEmbedded (Inverter) |
| signálové rozhraní | LVDS (2 ch, 6-bit), 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| rohs: | |
| aplikace | NBPC |
| B141EW04 V5 | AUO | 14.1 | 1280×800 |
| B141PW03 V0 | AUO | 14.1 | 1440×900 |
| LP141WX3-TLA3 | LG Display | 14.1 | 1280×800 |
| LP141WX3-TLB1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TPP1 | LG Display | 14.1 | 1280×800 |
| LTN141AT06-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT13-B01 | Samsung | 14.1 | 1280×800 |
| LTN141XB-L04 | Samsung | 14.1 | 1024×768 |
| N141I3-L01 | Innolux | 14.1 | 1280×800 |
| QD14FL02 Rev.01 | QDI | 14.1 | 1400×1050 |
| B125XW01 V0 | AUO | 12.5 | 1366×768 |
| B156XTN04.1 | AUO | 15.6 | 1366×768 |
| CLAA140UA01 CN | CPT | 14.0 | 1600×900 |
| CLAA156WA07A | CPT | 15.6 | 1366×768 |
| LP140WD2-TLB1 | LG Display | 14.0 | 1600×900 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LTD089EXWS | TOSHIBA | 8.9 | 1280×768 |
| LTN133AT16-L01 | Samsung | 13.3 | 1280×800 |
| LTN141XB-L04 | Samsung | 14.1 | 1024×768 |
| LTN154X1-L03 | Samsung | 15.4 | 1280×800 |
