| PartNumber | RGS32256064WH002 |
| Značka | RiTdisplay |
| Velikost | 3.2 |
| aplikace | IA |
| Rozlišení | 256×64 |
| Složení | OLED |
| Jas | 70 |
| CR | 2000:1 |
| Barvy | Mono(White) |
| Podsvícení | self |
| Rozhraní | CPU/SPI |
| značka panelu | RiTdisplay |
| panelový model | RGS32256064WH002 |
| typ panelu | PM-OLED , OLED |
| velikost panelu | 3.2 inch |
| rozlišení | 256×64 |
| aktivní oblast | 79.084×19.756 mm |
| obrys | 87.4×28.5×2.11 mm |
| povrch | Antiglare |
| jas | 70 cd/m² (Typ.) |
| kontrastní poměr | 2000 : 1 (Min.) |
| zobrazit barvy | Mono(White) (1-bit) |
| úhel pohledu | 80/80/80/80 (Min.)(L/R/U/D) |
| frekvence | 105Hz |
| řidič ic | COF Built-in SSD1322 |
| signálové rozhraní | 8-bit 6800/8080 parallel, 3/4-wire SPI, 34 pins |
| vstupní napětí | 14.5/2.8V (Typ.)(VCC/VCI) |
| aplikace | IA |
