| PartNumber | SVA156WX1-01TB |
| Značka | SVA-NEC |
| Velikost | 15.6 |
| aplikace | DMPC |
| Rozlišení | 1366×768 |
| Složení | LCM |
| Jas | 250 |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | SVA-NEC |
| panelový model | SVA156WX1-01TB |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.6 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 344.232×193.536 mm |
| obrys | 363.8×215.9×14.8 mm |
| povrch | |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193160% |
| Doba odezvy | 2/6 (Typ.)(Tr/Td) |
| úhel pohledu | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (1 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| B156HTN04.0 | AUO | 15.6 | 1920×1080 |
| B156XTK01.0 | AUO | 15.6 | 1366×768 |
| G156HTN02.1 | AUO | 15.6 | 1920×1080 |
| LM156WH1-TLE1 | LG Display | 15.6 | 1366×768 |
| LP156WD1-TLB4 | LG Display | 15.6 | 1600×900 |
| LP156WF1-TLA1 | LG Display | 15.6 | 1920×1080 |
| LP156WF1-TLB2 | LG Display | 15.6 | 1920×1080 |
| LTN156AT05-B01 | Samsung | 15.6 | 1366×768 |
| N156B3-L0B | Innolux | 15.6 | 1366×768 |
| SVA156WX1-01TB | SVA-NEC | 15.6 | 1366×768 |
| LM150X08-A4KD | LG Display | 15.0 | 1024×768 |
| LM201U04-A3KC | LG Display | 20.1 | 1600×1200 |
| LM340WW1-SSA1 | LG Display | 34 | 2560×1080 |
| M150EW01 V0 | AUO | 15.0 | 1280×720 |
| M170EG01 VG | AUO | 17.0 | 1280×1024 |
| M190EG02 V9 | AUO | 19.0 | 1280×1024 |
| M270DTN01.0 | AUO | 27.0 | 2560×1440 |
| MT190AW01 V.C | Innolux | 19.0 | 1440×900 |
| MV190E0M-N10 | BOE | 19.0 | 1280×1024 |
| NL128102BC29-01B | NLT | 19.0 | 1280×1024 |
