| PartNumber | SX25S004 |
| Značka | KOE |
| Velikost | 10.0 |
| aplikace | IA |
| Rozlišení | 800×600 |
| Složení | LCM |
| Jas | 100 |
| CR | 50:1 |
| Barvy | Color |
| Podsvícení | CCFL |
| Rozhraní | Parallel Data |
| značka panelu | HITACHI |
| panelový model | SX25S004 |
| typ panelu | CSTN-LCD , LCM |
| velikost panelu | 10.0 inch |
| rozlišení | 800(RGB)×600 , SVGA |
| zobrazovací mód | STN, Normally Black, Transmissive |
| aktivní oblast | 202.8×152.1 mm |
| obrys | 236×168×6.3 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 100 cd/m² (Typ.) |
| kontrastní poměr | 50:1 (Typ.) |
| zobrazit barvy | Color |
| Doba odezvy | 170/130 (Typ.)(Tr/Td) |
| úhel pohledu | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| frekvence | 120Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhraní | Parallel Data (2ch, 8-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
