| PartNumber | TD170WGCB2 |
| Značka | TPO |
| Velikost | 17.0 |
| aplikace | DMPC |
| Rozlišení | 1280×1024 |
| Složení | LCM |
| Jas | 260 |
| CR | 450:1 |
| Barvy | 16.2M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | Toppoly |
| panelový model | TD170WGCB2 10 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 17.0 inch |
| rozlišení | 1280(RGB)×1024 , SXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 337.92×270.336 mm |
| obrys | 358.5×296.5×17.5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 260 cd/m² (Typ.) |
| kontrastní poměr | 450:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC), CIE193172% |
| Doba odezvy | 3/9 (Typ.)(Tr/Td) |
| úhel pohledu | 75/75/75/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| HSD170MGW1-B00 | HannStar | 17.0 | 1440×900 |
| LM170E01-TLBF | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLG1 | LG Display | 17.0 | 1280×1024 |
| LTM170E6-L03 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L21 | Samsung | 17.0 | 1280×1024 |
| LTN170BT05-G01 | Samsung | 17.0 | 1440×900 |
| LTN170BT09-001 | Samsung | 17.0 | 1440×900 |
| LTN170CT08-D01 | Samsung | 17.0 | 1920×1200 |
| TD170WGCA1 | TPO | 17.0 | 1280×1024 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
| IAQX10M | IDTech | 15.0 | 2048×1536 |
| LM150X06-A4C4 | LG Display | 15.0 | 1024×768 |
| LM171WX3-TLA1 | LG Display | 17.1 | 1440×900 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| M200FGE-L20 | Innolux | 20.0 | 1600×900 |
| M201P1-L03 | Innolux | 20.1 | 1400×1050 |
| M220Z1-L03 | Innolux | 22.0 | 1680×1050 |
| MT170EN01 V.9 | Innolux | 17.0 | 1280×1024 |
| TD170WGCA1 | TPO | 17.0 | 1280×1024 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
