| PartNumber | LM185WH2-TLD1 |
| Značka | LG Display |
| Velikost | 18.5 |
| aplikace | DMPC |
| Rozlišení | 1366×768 |
| Složení | LCM |
| Jas | 200 |
| CR | 600:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | LG Display |
| panelový model | LM185WH2-TLD1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 18.5 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 409.8×230.4 mm |
| obrys | 430.4×254.6×10.7 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC) |
| Doba odezvy | 1.1/3.9 (Typ.)(Tr/Td) |
| úhel pohledu | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 11S2PWLEDWithout Driver |
| signálové rozhraní | LVDS (1 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| LM185WH1-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLC5 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLD3 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLF1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLF4 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLH1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-T2BB | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLE2 | LG Display | 18.5 | 1366×768 |
| LM200WD1-TLC1 | LG Display | 20.0 | 1600×900 |
| LM215WF1-TLB1 | LG Display | 21.5 | 1920×1080 |
| LM230WF5-TLC1 | LG Display | 23.0 | 1920×1080 |
| LTM190EX-L05 | Samsung | 19.0 | 1280×1024 |
| M170EP01 V0 | AUO | 17.0 | 1280×1024 |
| M185BGE-L2U | Innolux | 18.5 | 1366×768 |
| M190EN03 V0 | AUO | 19.0 | 1280×1024 |
| M215HJK-L3B | Innolux | 21.5 | 1920×1080 |
| M240HTN01.1 | AUO | 24.0 | 1920×1080 |
| MT190AW01 V.5 | Innolux | 19.0 | 1440×900 |
