| PartNumber | HSD040I3N1-B00 |
| Značka | HannStar |
| Velikost | 4.0 |
| aplikace | CNS |
| Rozlišení | 320×240 |
| Složení | LCM |
| Jas | 4700 |
| CR | 350:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | HannStar |
| panelový model | HSD040I3N1-B00 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.0 inch |
| rozlišení | 320(RGB)×240 , QVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 82.08×61.56 mm |
| obrys | 112.11×80.51×8.3 mm |
| povrch | |
| jas | 4700 cd/m² (Typ.) |
| kontrastní poměr | 350:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193145% |
| Doba odezvy | 4/12 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/60/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | CNS |
