| PartNumber | TX06D15VM1EAA |
| Značka | KOE |
| Velikost | 2.2 |
| aplikace | MPH |
| Rozlišení | 176×220 |
| Složení | LCM |
| Jas | 60 |
| CR | 40:1 |
| Barvy | 65K/262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | HITACHI |
| panelový model | TX06D15VM1EAA |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 2.2 inch |
| rozlišení | 176(RGB)×220 , QCIF+ |
| zobrazovací mód | IPS, Normally Black, Transflective |
| aktivní oblast | 34.848×43.56 mm |
| obrys | 41.85×56 mm |
| povrch | |
| jas | 60 cd/m² (Typ.) |
| kontrastní poměr | 40:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| zobrazit barvy | 65K/262K |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | |
| typ lampy | 1S3PWLED |
| signálové rozhraní | Parallel RGB + SPI, 45 pins |
| vstupní napětí | 2.8/2.8V (Typ.)(VCC/VCI) |
| rohs: | |
| aplikace | MPH |
