| PartNumber | CT022TN15 |
| Značka | Innolux |
| Velikost | 2.2 |
| aplikace | MPH |
| Rozlišení | 176×220 |
| Složení | LCM |
| Jas | 200 |
| CR | 300:1 |
| Barvy | 65K/262K |
| Podsvícení | WLED |
| Rozhraní | CPU |
| značka panelu | INNOLUX |
| panelový model | CT022TN15 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 2.2 inch |
| rozlišení | 176(RGB)×220 , QCIF+ |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 34.848×43.56 mm |
| obrys | 42.3×57.5 mm |
| povrch | |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 300:1 (Typ.) |
| zobrazit barvy | 65K/262K , CIE193150% |
| Doba odezvy | 30 (Typ.)(Tr+Td) |
| úhel pohledu | 55/55/55/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4S1PWLEDWithout Driver |
| signálové rozhraní | CPU, 20 pins |
| vstupní napětí | 3.3/3.3V (Typ.)(VDD/VCI) |
| aplikace | MPH |
