| PartNumber | TX26D12VM0APA |
| Značka | KOE |
| Velikost | 10.4 |
| aplikace | IA |
| Rozlišení | 800×600 |
| Složení | LCM |
| Jas | 360 |
| CR | 800:1 |
| Barvy | 262K/16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | HITACHI |
| panelový model | TX26D12VM0APA |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.4 inch |
| rozlišení | 800(RGB)×600 , SVGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 211.2×158.4 mm |
| obrys | 243×185.1 mm |
| povrch | Antiglare |
| jas | 360 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193154% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S8PWLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 6/8-bit), 20 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
| B104SN01 V0 | AUO | 10.4 | 800×600 |
| KCB6448BSTT-X1 | Kyocera | 10.4 | 640×480 |
| LQ104V1DG71 | SHARP | 10.4 | 640×480 |
| LTD104KA1S | TOSHIBA | 10.4 | 1024×768 |
| NL6448AC33-10 | NLT | 10.4 | 640×480 |
| TX26D11VM1CAA | KOE | 10.4 | 640×480 |
| TX26D12VM0AAA | KOE | 10.4 | 800×600 |
| TX26D12VM0APA | KOE | 10.4 | 800×600 |
| TX26D14VM2EAA | KOE | 10.4 | 640×480 |
| TX26D17VM2BAA | KOE | 10.4 | 640×480 |
| AA070ME01-DA1 | Mitsubishi | 7.0 | 800×480 |
| BA104S01-100 | BOE | 10.4 | 800×600 |
| ER057005NC6 | EDT | 5.7 | 320×240 |
| G185BGE-L01 | Innolux | 18.5 | 1366×768 |
| LM12S471 | SHARP | 12.1 | 800×600 |
| LM641836R | SHARP | 9.4 | 640×480 |
| LM8V302 | SHARP | 7.7 | 640×480 |
| LQ070Y3LG05 | SHARP | 7.0 | 800×480 |
| LQ10D131 | SHARP | 10.4 | 640×480 |
| LTA084C270F | TOSHIBA | 8.4 | 800×600 |
