| PartNumber | R190E5-L01 |
| Značka | Innolux |
| Velikost | 19.0 |
| aplikace | MD |
| Rozlišení | 1280×1024 |
| Složení | LCM |
| Jas | 1300 |
| CR | 1000:1 |
| Barvy | Grayscale |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | CMO |
| panelový model | R190E5-L01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 19.0 inch |
| rozlišení | 1280(LCR)×1024 , SXGA |
| zobrazovací mód | DD-IPS, Normally Black, Transmissive |
| aktivní oblast | 376.32×301.056 mm |
| obrys | 396×324×37 mm |
| povrch | Antiglare |
| jas | 1300 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | Grayscale (8-bit) |
| Doba odezvy | 15/5 (Typ.)(Tr/Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥20)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 14 pcsCCFLEmbedded (Inverter) |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | MD |
| HSD190ME12-A10 | HannStar | 19.0 | 1280×1024 |
| LM190E08-TLL3 | LG Display | 19.0 | 1280×1024 |
| LM190WX1-TLC1 | LG Display | 19.0 | 1440×900 |
| LTB190E2-L01 | Samsung | 19.0 | 1280×1024 |
| NL128102AC29-17 | NLT | 19.0 | 1280×1024 |
| NL128102BC29-01C | NLT | 19.0 | 1280×1024 |
| R190E5-L01 | Innolux | 19.0 | 1280×1024 |
| R190E6-L01 | Innolux | 19.0 | 1280×1024 |
| R190EFE-L51 | Innolux | 19.0 | 1280×1024 |
| R190EFE-L61 | Innolux | 19.0 | 1280×1024 |
| G213QAN01.0 | AUO | 21.3 | 2048×1536 |
| ITQX21K | IDTech | 20.8 | 2048×1536 |
| LQ201U1LW11Z | SHARP | 20.1 | 1600×1200 |
| NL160120AC27-37 | NLT | 21.3 | 1600×1200 |
| NL204153BM21-05A | NLT | 21.3 | 2048×1536 |
| R190E5-L01 | Innolux | 19.0 | 1280×1024 |
| R213T3-L01 | Innolux | 21.3 | 2560×2048 |
| R213T3-L02 | Innolux | 21.3 | 2560×2048 |
| VVX21F136J00 | Panasonic | 21.3 | 1600×1200 |
| VVX28T143H00 | Panasonic | 28.0 |
