| PartNumber | V580DK2-QS1 |
| Značka | Innolux |
| Velikost | 58 |
| aplikace | LCTV |
| Rozlišení | 3840×2160 |
| Složení | CELL |
| Jas | 0 |
| CR | 4000:1 |
| Barvy | 16.7M |
| Podsvícení | No B/L |
| Rozhraní | V-by-One |
| značka panelu | CHIMEI INNOLUX |
| panelový model | V580DK2-QS1 |
| typ panelu | a-Si TFT-LCD , CELL |
| velikost panelu | 58 inch |
| rozlišení | 3840(RGB)×2160 , UHD |
| zobrazovací mód | Super MVA, Normally Black, Transmissive |
| aktivní oblast | 1270.08×721.44 mm |
| obrys | 1282.88×734.44 mm |
| povrch | Antiglare (Haze 1%) |
| hloubka skla | 0.70+0.70 mm |
| propustnost | 4.3% (Typ.)(with Polarizer) |
| kontrastní poměr | 4000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 9.5 (Typ.)(G to G) |
| úhel pohledu | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvence | 120Hz |
| signálové rozhraní | V-by-One 8 lane, 51 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | LCTV |
