| PartNumber | V650DK1-LS1 |
| Značka | Innolux |
| Velikost | 65 |
| aplikace | LCTV |
| Rozlišení | 3840×2160 |
| Složení | LCM |
| Jas | 400 |
| CR | 5000:1 |
| Barvy | 1.07B |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | CHIMEI INNOLUX |
| panelový model | V650DK1-LS1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 65 inch |
| rozlišení | 3840(RGB)×2160 , UHD |
| zobrazovací mód | Super MVA, Normally Black, Transmissive |
| aktivní oblast | 1428.48×803.52 mm |
| obrys | 1450.5×828.5 mm |
| povrch | Antiglare (Haze 1%), Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 5000:1 (Typ.) |
| zobrazit barvy | 1.07B (8-bit + Hi-FRC), CIE193172% |
| Doba odezvy | 8.5 (Typ.)(G to G) |
| úhel pohledu | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvence | 120Hz |
| typ lampy | 4 stringsWLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (4 ch, 10-bit), 102 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | LCTV |
| P650HVN02.3 | AUO | 65 | 1920×1080 |
| P650HVN02.6 | AUO | 65 | 1920×1080 |
| T645HW04 V0 CELL | AUO | 65 | 1920×1080 |
| T650HVD01.0 | AUO | 65 | 1920×1080 |
| T650HVN07.3 | AUO | 65 | 1920×1080 |
| T650QVD01.0 CELL | AUO | 65 | 3840×2160 |
| T650QVR03.0 | AUO | 65 | 3840×2160 |
| V650DJ4-KS5 | Innolux | 65 | 3840×2160 |
| V650DK1-LS1 | Innolux | 65 | 3840×2160 |
| V650DK1-QS1 | Innolux | 65 | 3840×2160 |
| HK185LEDM-CH25H | Other | 18.5 | 1366×768 |
| HV650QUB-B00 | BOE | 65 | 3840×2160 |
| LC260EUN-SCA1 | LG Display | 26.0 | 1920×1080 |
| LC320WXN-SAC2 | LG Display | 31.5 | 1366×768 |
| LC420EUF-SCR1 | LG Display | 42 | 1920×1080 |
| LTA320AP02 | Samsung | 31.5 | 1366×768 |
| LTA400HL04 | Samsung | 40 | 1920×1080 |
| T240XW01 V0 | AUO | 24.0 | 1366×768 |
| T315XW02 VM | AUO | 31.5 | 1366×768 |
| T390HVF01.0 | AUO | 39 | 1920×1080 |
