| PartNumber | VVX11F009G00 |
| Značka | Panasonic |
| Velikost | 11.6 |
| aplikace | PAD |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 570 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | Panasonic |
| panelový model | VVX11F009G00 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 11.6 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | IPS-Pro, Normally Black, Transmissive |
| aktivní oblast | 256.896×144.504 mm |
| obrys | 268.896×166.564 mm |
| povrch | Antiglare |
| jas | 570 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 26 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 7S5PWLEDEmbedded (LED Driver) |
| signálové rozhraní | eDP (2 Lanes), 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
