| PartNumber | A035VL01 V6 |
| Značka | AUO |
| Velikost | 3.5 |
| aplikace | DSC |
| Rozlišení | 800×480 |
| Složení | LCM |
| Jas | 315 |
| CR | 800:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | AUO |
| panelový model | A035VL01 V6 |
| typ panelu | LTPS TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 800(RGB)×480 , WVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 75.6×45.36 mm |
| obrys | 86.1×51.66 mm |
| povrch | Glare (Haze 0%) |
| jas | 315 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 15/30 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 5S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit) + SPI, 70 pins |
| vstupní napětí | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| aplikace | DSC |
