| PartNumber | A040FL01 V2 |
| Značka | AUO |
| Velikost | 4.0 |
| aplikace | PND |
| Rozlišení | 480×272 |
| Složení | LCM |
| Jas | 300 |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | AUO |
| panelový model | A040FL01 V2 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.0 inch |
| rozlišení | 480(RGB)×272 , WQVGA |
| zobrazovací mód | ATR-MVA, Normally Black, Transflective |
| aktivní oblast | 87.84×49.776 mm |
| obrys | 98.3×62.6 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.)(Transmissive) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 20/20 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 8S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| vstupní napětí | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| aplikace | PND |
| A040FL01 V2 | AUO | 4.0 | 480×272 |
| AMS395GB04 | Samsung | 4.0 | 360×640 |
| COM40T4M46ULX | ORTUSTECH | 4.0 | 480×800 |
| LB040Q02-TD02 | LG Display | 4.0 | 320×240 |
| LB040Q02-TD05 | LG Display | 4.0 | 320×240 |
| LH400WS2-SD03 | LG Display | 4.0 | 640×1136 |
| LH400WV3-SD02 | LG Display | 4.0 | 480×800 |
| LH400WV3-SD05 | LG Display | 4.0 | 480×800 |
| LS040B3SX01 | SHARP | 4.0 | 640×960 |
| LTE400WQ-E01 | Samsung | 4.0 | 480×272 |
| A050FW03 V2 | AUO | 5.0 | 480×272 |
| DLC0500HZG-T-8 | Other | 5.0 | 800×480 |
| HE050NA-01F | Innolux | 5.0 | 800×480 |
| LMS500HF13-003 | Samsung | 5.0 | 480×272 |
| LQ035Q1DG02 | SHARP | 3.5 | 320×240 |
| LQ043T3DG02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX02 | SHARP | 4.3 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
| PT035TN01 V.3 | Innolux | 3.5 | 320×240 |
