| PartNumber | LH400WV3-SD05 |
| Značka | LG Display |
| Velikost | 4.0 |
| aplikace | MPH |
| Rozlišení | 480×800 |
| Složení | LCM |
| Jas | 700 |
| CR | 800:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | LG Display |
| panelový model | LH400WV3-SD05 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.0 inch |
| rozlišení | 480(RGB)×800 , WVGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 51.84×86.4 mm |
| obrys | 55.54×95.8 mm |
| povrch | Clear |
| jas | 700 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193170% |
| Doba odezvy | 20/20 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1S8PWLEDWithout Driver |
| signálové rozhraní | MIPI (2 data lanes), 30 pins |
| vstupní napětí | 1.8/2.8/2.8 (Typ.)(IOVCC/VCC/VCI) |
| aplikace | MPH |
