| PartNumber | A056VN01 V0 |
| Značka | AUO |
| Velikost | 5.6 |
| aplikace | |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 350 |
| CR | 400:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | AUO |
| panelový model | A056VN01 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.6 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 112.8×84.6 mm |
| obrys | 126.5×100 mm |
| povrch | Antiglare |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 15/25 (Typ.)(Tr/Td) |
| úhel pohledu | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 3S7PWLEDEmbedded (LED Driver) |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit) + SPI, 40 pins |
| vstupní napětí | 3.3V (Typ.)(VDD) |
| rohs: |
