| PartNumber | A061FW01 V0 |
| Značka | AUO |
| Velikost | 6.1 |
| aplikace | CNS |
| Rozlišení | 480×234 |
| Složení | LCM |
| Jas | 450 |
| CR | 500:1 |
| Barvy | Full color |
| Podsvícení | WLED |
| Rozhraní | Analog |
| značka panelu | AUO |
| panelový model | A061FW01 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 6.1 inch |
| rozlišení | 480(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 136.08×71.955 mm |
| obrys | 149×82.9 mm |
| povrch | Antiglare (Haze 25%) |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | Full color , CIE193150% |
| Doba odezvy | 15/20 (Typ.)(Tr/Td) |
| úhel pohledu | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 6S3PWLEDWithout Driver |
| signálové rozhraní | TFT Specific Analog RGB, 30 pins |
| vstupní napětí | 3.3/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| aplikace | CNS |
