| PartNumber | CLAA061LA0DCW |
| Značka | CPT |
| Velikost | 6.1 |
| aplikace | CNS |
| Rozlišení | 800×480 |
| Složení | LCM |
| Jas | 500 |
| CR | 400:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | CPT |
| panelový model | CLAA061LA0DCW |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 6.1 inch |
| rozlišení | 800(RGB)×480 , WVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 136.2×72 mm |
| obrys | 149×82.9×6.36 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 500 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193170% |
| Doba odezvy | 20 (Typ.)(Tr+Td) |
| úhel pohledu | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S4PWLEDWithout Driver |
| signálové rozhraní | TTL (1 ch, 6-bit), 60 pins |
| vstupní napětí | 3.3/9.2/18/-6V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikace | CNS |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| CLAA062LA01CW | CPT | 6.2 | 800×480 |
| CLAA069JA11CW | CPT | 7.0 | 480×234 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB02CW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| C043GW01 V0 | AUO | 4.3 | 400×234 |
| CLAA088WA01XN | CPT | 8.8 | 1280×480 |
| DJ080PA-01C | Innolux | 8.0 | |
| DLC0700DDG-4 | Other | 7.0 | 800×480 |
| HSD080IFW1-A00 | HannStar | 8.0 | 1024×600 |
| LA092WV1-SD01 | LG Display | 9.2 | 800×480 |
| LQ049B5DG04 | SHARP | 4.9 | 320×96 |
| TFD65W46 | TOSHIBA | 6.5 | 480×234 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
