| PartNumber | AA043MA01 |
| Značka | Mitsubishi |
| Velikost | 4.3 |
| aplikace | IA |
| Rozlišení | 800×480 |
| Složení | LCM |
| Jas | 200 |
| CR | 400:1 |
| Barvy | 262K/16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | Mitsubishi |
| panelový model | AA043MA01 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.3 inch |
| rozlišení | 800(RGB)×480 , WVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 93×55.8 mm |
| obrys | 103×67.5×5.8 mm |
| povrch | Clear, Hard coating (2H) |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| Doba odezvy | 5/20 (Typ.)(Tr/Td) |
| úhel pohledu | 65/65/65/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 stringsWLEDWithout Driver |
| signálové rozhraní | CMOS (1 ch, 6/8-bit), 45 pins |
| vstupní napětí | 3.3V (Typ.)(VCC) |
| aplikace | IA |
| AA043MA01 | Mitsubishi | 4.3 | 800×480 |
| AMS427GL34-1 | Samsung | 4.3 | 480×800 |
| AT043TN25 V.2 | Innolux | 4.3 | 480×272 |
| C043FW01 V0 | AUO | 4.3 | 480×234 |
| LMS430HF02 | Samsung | 4.3 | 480×272 |
| LQ043T1DH41 | SHARP | 4.3 | 480×272 |
| LQ043Y1DX03D | SHARP | 4.3 | 480×800 |
| LR430RC9601 | Innolux | 4.3 | 480×272 |
| LTE430WQ-F0B | Samsung | 4.3 | 480×272 |
| YX-CM043-QN05-56 | 4.3 | 480×272 |
| AA150XN09 | Mitsubishi | 15.0 | 1024×768 |
| EL640.400-CB1 FRA | Lumineq | 9.1 | 640×400 |
| EW50855BMW | EDT | 4.7 | 320×240 |
| G121I1-L01 | Innolux | 12.1 | 1280×800 |
| LM64183P | SHARP | 9.4 | 640×480 |
| LM64P10 | SHARP | 7.2 | 640×480 |
| LTA150B851F | TOSHIBA | 15.0 | 1024×768 |
| NL6448BC33-64R | NLT | 10.4 | 640×480 |
| PM070WL1 | E Ink | 7.0 | 800×480 |
| TM057QDHG04 | Tianma | 5.7 | 640×480 |
