| PartNumber | ACM019A |
| Značka | Other |
| Velikost | 2.4 |
| aplikace | IA |
| Rozlišení | 128×64 |
| Složení | LCM |
| Jas | |
| CR | |
| Barvy | Monochrome |
| Podsvícení | WLED |
| Rozhraní | SPI |
| značka panelu | Amson |
| panelový model | ACM019A |
| typ panelu | FSTN-LCD , LCM |
| velikost panelu | 2.4 inch |
| rozlišení | 128×64 |
| zobrazovací mód | STN, Blue/Grey (Positive), Transflective |
| aktivní oblast | 55.01×27.49 mm |
| obrys | 74.8×54.5×8 mm |
| povrch | |
| jas | |
| kontrastní poměr | |
| zobrazit barvy | Monochrome |
| Doba odezvy | |
| úhel pohledu | |
| typ lampy | WLEDWithout Driver |
| signálové rozhraní | SPI, 18 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
