| PartNumber | M070SWP1 R4 |
| Značka | IVO |
| Velikost | 7.0 |
| aplikace | IA |
| Rozlišení | 800×480 |
| Složení | LCM |
| Jas | 500 |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | IVO |
| panelový model | M070SWP1 R4 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 800(RGB)×480 , WVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 153.6×86.64 mm |
| obrys | 165×104×5.3 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 500 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193150% |
| Doba odezvy | 16 (Typ.)(Tr+Td) |
| úhel pohledu | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 8S2PWLEDWithout Driver |
| signálové rozhraní | TTL (1 ch, 8-bit), 60 pins |
| vstupní napětí | 3.3/10.4/22/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikace | IA |
| C070VVN03.1 | AUO | 7.0 | 800×480 |
| CLAA070LH01AW | CPT | 7.0 | 800×480 |
| CLAA070NQ01 XN | CPT | 7.0 | 1024×600 |
| CLAP070WP03XG | CPT | 7.0 | 800×1280 |
| DD070NA-02A | Innolux | 7.0 | 800×480 |
| LB070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LT070CB01000 | TOSHIBA | 7.0 | |
| M070SW46 R0 | IVO | 7.0 | 1200×1920 |
| M070SWP1 R4 | IVO | 7.0 | 800×480 |
| M070SWP1 R5 | IVO | 7.0 | 800×480 |
| A150XN01 V2 | AUO | 15.0 | 1024×768 |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| G220SW02 V0 | AUO | 22.0 | 1680×1050 |
| LM340UW1-SSA1 | LG Display | 34 | 3440×1440 |
| LQ121S1LG84 | SHARP | 12.1 | 800×600 |
| LQ156M3LW01 | SHARP | 15.6 | 1920×1080 |
| LTM08C351S | TOSHIBA | 8.4 | 800×600 |
| NL8060BC31-17 | NLT | 12.1 | 800×600 |
| UG-2864ASWPG01 | WiseChip | 2.4 | 128×64 |
