| PartNumber | LD050WQ1-TD02 |
| Značka | LG Display |
| Velikost | 5.0 |
| aplikace | DPF |
| Rozlišení | 480×272 |
| Složení | LCM |
| Jas | |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | |
| značka panelu | LG Display |
| panelový model | LD050WQ1-TD02 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 480×272(RGB) , WQVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 110.88×62.832 mm |
| povrch | |
| jas | |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Dithering), CIE193148% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 70/70/65/55 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | WLED |
| aplikace | DPF |
