| PartNumber | AT056TN52 V.5 |
| Značka | Innolux |
| Velikost | 5.6 |
| aplikace | |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 280 |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | INNOLUX |
| panelový model | AT056TN52 V.5 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.6 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 112.896×84.672 mm |
| obrys | 126.5×100×8.6 mm |
| povrch | Hard coating (3H) |
| jas | 280 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193150% |
| Doba odezvy | 10/15 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/45/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins |
| vstupní napětí | 3.3V (Typ.) |
