| PartNumber | BP080WX1-100 |
| Značka | BOE |
| Velikost | 8.0 |
| aplikace | PAD |
| Rozlišení | 1280×800 |
| Složení | LCM |
| Jas | |
| CR | 900:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | BOE |
| panelový model | BP080WX1-100 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 8.0 inch |
| rozlišení | 1280(RGB)×800 , WXGA |
| zobrazovací mód | HFFS, Normally Black, Transmissive |
| aktivní oblast | 172.224×107.64 mm |
| povrch | Hard coating (3H) |
| jas | |
| kontrastní poměr | 900:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC) |
| Doba odezvy | 24 (Typ.)(Tr+Td) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | WLED |
| signálové rozhraní | MIPI (4 data lanes) |
| aplikace | PAD |
