| PartNumber | CLAA098EP01XG |
| Značka | CPT |
| Velikost | 9.8 |
| aplikace | |
| Rozlišení | 1280×960 |
| Složení | LCM |
| Jas | 400 |
| CR | 900:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | CPT |
| panelový model | CLAA098EP01XG |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 9.8 inch |
| rozlišení | 1280(RGB)×960 , Quad-VGA |
| zobrazovací mód | HFFS, Normally Black, Transmissive |
| aktivní oblast | 199.68×149.76 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 900:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193150% |
| Doba odezvy | 30 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 8-bit) + SPI |
