| PartNumber | CLAA220WA01 |
| Značka | CPT |
| Velikost | 21.6 |
| aplikace | DMPC |
| Rozlišení | 1680×1050 |
| Složení | LCM |
| Jas | 300 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | CPT |
| panelový model | CLAA220WA01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 21.6 inch |
| rozlišení | 1680(RGB)×1050 , WSXGA+ |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 464.94×290.587 mm |
| obrys | 493.7×320.1 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Doba odezvy | 5 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
